PCB

Procurement Of Components

No.	Types Of Assembly	File Format	Component Footprinr	Component Package	Testing Produres	Produres	Others
1	SMT ASSEMBLY	Gerber RS-274X	0201,0402,0603…	Reels Package	Visual Inspection	Lead-Free(Rohs)	Custom Reflow Profile
2	SMT & THT Assembly	BOM(.xls,.csv,.xlsx)	BGA,QFN,QFP,PLCC	Cut Tape Package	X-Ray Inspection	Leaded Solder	Standard Reflow Profile
3	2 sided STM,THT Assembly	Pick-N-Place/XY file	SOIC,POP…Connectors	Tube and Tray	AOI,ICT(In-Circuit Test)	Reflow Soldering	Smallest Size:0.2″x0.2″
4	Mixed Assembly	…	Small Pitch of 8 Mils	Loose parts and bulk	Functional Testing	Wave Soldering	Largest Size:15″x”20

Layer	1-20 layer
Material Type	FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers
Board Thickness	0.21mm to 7.0mm
Copper Thickness	0.5 OZ to 6 oz
Size（Custom）	Max. Board Size: 580mm×1100mm
	Min. Drilled Hole Size: 0.2 mm (8 mil)
	Min. Line Width: 4mil (0.1mm)
	Min. Line Spacing: 4mil (0.1mm)
Surface Finishing	HASL / HASL lead free, HAL, Chemical tin,
Surface Finishing	Immersion Silver / Gold, OSP, Gold plating
Solder Mask Color	Green / Yellow / Black / White / Red / Blue
Tolerance	Shape tolerance: ±0.13
Tolerance	Hole tolerance: PTH: ±0.076 NPTH: ±0.05
Certificate	International Certification Standards
Special Requirements	Buried and blind vias+controlled impedance +BGA
Profiling	Punching, Routing, V-CUT, Beveling
