We focus on multi-layer printed circuit boards, impedance Controlled circuit boards and HDI PCBs in varying complexities, and we offer a wide range of helpful Cost-Free Options to make sure our clients always receive the best possible product.
1. Maximum Panel size: 19.7″ x 31.5″
2. Maximum Number of Layers: 1-40
3. Copper Thickness: 0.5 oz to 5.0 oz
4. Minimum Line Width: 3 mil
5. Minimum Line spacing: 3 mil
6. Smallest Hole: 0.006″
7. Blind, Buried and plugged Vias
8. Controlled impedance
1. Thickness: 0.008″ to 0.240″
2. FR-4
3. High TG FR-4
4. PTFE
5. Aluminum Base
6. Rogers
7. Specialized material per your request
1. LPI – Green, Yellow, Black, Red, Blue, White, etc. (Inquire for more options)
2. Peelable Adhesive
1. SMOBC (HASL)
2. Carbon
3. Selective Gold Plating
4. Hard and Soft Gold
5. Immersion Gold
6. Immersion Silver
7. Immersion Tin
8. OSP
1. White, Yellow, Black (Inquire for more options)
2. Inspection Methods
3. 100% Visual inspection
4. Electrical testing – Flying probe or Nails Bed
5. Sample lot inspection
6. Cross sectioning
1. Rush: 24 Hours
2. Standard Prototype: 5 days
3. Standard Production: 10 days
